A suite of class-leading technological innovations drawn from The Reference for exceptional acoustic performance.
An icon born from The Reference
Absorbs 99% of unwanted sound for pure and natural sound.
Metamaterial Absorption Technology
Hybrid aluminium bass drivers with greater driver excursion for tight, deep, controlled bass.
True bass definition
Acts as a single point source to enlarge the 'sweet spot' and disperse sound more evenly.
12th generation Uni-Q®
With 1801 precision-cut holes for each driver, performance is ensured even when the drivers are covered.
Microfibre grilles
Previous slide
Next slide
Specifications
DESIGN :Three-way bass reflex


DRIVE UNITS
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass Unit:
LF: 165 mm (6.5 in.) hybrid aluminium cone


CROSSOVER FREQUENCY
420 Hz, 2.3 kHz


FREQUENCY RANGE (-6dB)
38 Hz - 50 kHz


TYPICAL IN-ROOM BASS RESPONSE (-6dB)
30 Hz


FREQUENCY RESPONSE (±3dB)
58Hz - 28kHz


HARMONIC DISTORTION (90dB, 1m)
<1% 73 Hz and above
<0.5% 90 Hz - 20 kHz


MAXIMUM OUTPUT
110 dB


AMPLIFIER REQUIREMENTS
15 - 180W


NOMINAL IMPEDANCE
4 Ω (min. 3.2 Ω)


SENSITIVITY (2.83V/1m)
87 dB


WEIGHT *
12.4 kg (27.3 lbs)


DIMENSION (H x W x D) WITH TERMINAL *
422 x 200 x 336 mm (16.6 x 7.9 x 13.2 in)


FINISHES
  • Black Gloss
  • White Gloss
  • Walnut
  • Indigo Gloss Special Edition

* Measurement per unit
In the Box
  • 1 pair of R3 Meta loudspeakers
  • 1 pair of microfiber grilles
  • Rubber feet
  • Port bungs
  • User manual and warranty information
Pictures for illustration only
Pictures for illustration only
Pictures for illustration only
Pictures for illustration only
Pictures for illustration only
Pictures for illustration only
Previous slide
Next slide
KEF Color

Gloss Black, Gloss White
