A suite of class-leading technological innovations drawn from The Reference for exceptional acoustic performance.
An icon born from The Reference
Technology Absorbs 99% of unwanted sound for pure and natural sound.
Metamaterial Absorption
Hybrid aluminium bass drivers with greater driver excursion for tight, deep, controlled bass.
True bass definition
Acts as a single point source to enlarge the 'sweet spot' and disperse sound more evenly.
12th generation Uni-Q®
With a choice of matching home theatre models to pair with, the stage is set for an immersive movie experience.
Home theatre made versatile
With 1801 precision-cut holes for each driver, performance is ensured even when the drivers are covered.
Microfibre grilles
Previous slide
Next slide
SPECIFICATIONS
DESIGN
Three-way bass reflex


DRIVE UNITS
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass Unit:
LF: 2 x 165 mm (6.5 in.) hybrid aluminium cone


CROSSOVER FREQUENCY
400 Hz, 2.4 kHz


FREQUENCY RANGE (-6dB)
33 Hz - 50 kHz


TYPICAL IN-ROOM BASS RESPONSE (-6dB)
27 Hz


FREQUENCY RESPONSE (±3dB)
48 Hz - 28 kHz


HARMONIC DISTORTION (90dB, 1m)
<1% 76 Hz and above
<0.5% 110 Hz - 20 kHz


MAXIMUM OUTPUT
111 dB


AMPLIFIER REQUIREMENTS
15 - 250W


NOMINAL IMPEDANCE
4 Ω (min. 3.2 Ω)


SENSITIVITY (2.83V/1m)
88 dB


WEIGHT *
29.3 kg (64.6 lbs)


DIMENSION (H x W x D) WITH TERMINAL *
1062 x 200 x 384 mm (41.8 x 7.9 x 15.1 in.)


DIMENSION (H x W x D) WITH TERMINAL WITH PLINTH *
1109 x 311 x 384 mm (43.7 x 12.2 x 15.1 in.)


FINISHES
  • Black Gloss
  • White Gloss
  • Walnut
  • Titanium Gloss Special Edition
In the Box
  • R7 Meta
  • Microfiber grille
  • Plinth and spike accessories
  • Port bungs
  • User manual and warranty information
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
GALLERY
KEF R7 META
Previous slide
Next slide
KEF Color

Gloss Black, Titanium Grey, Walnut
